HT802 Series Heavy Duty 5A 125/250VAC Industrial Toggle Switch For Heavy Machine
Introducing the HT802 Series Heavy-Duty Industrial Toggle Switch—a purpose-built control solution rated for 5A at 125/250VAC, engineered to deliver unwavering reliability in the rigorous operation of heavy machinery. Designed as a trusted component for high-stress industrial environments, this switch merges robust construction with precise performance to minimize downtime and maximize operational efficiency.
With its 5A 125/250VAC rating, the HT802 Series handles a wide range of industrial loads—including resistive, inductive, and lamp circuits—making it versatile for applications like mining equipment, construction machinery, agricultural tractors, and manufacturing presses. Its silver-plated contacts ensure low resistance and minimal arcing, reducing wear and extending service life, while the single or double pole configurations (per model) cater to diverse circuit control needs.
Crafted for heavy-duty resilience, the switch features a zinc alloy or anodized aluminum housing that resists corrosion, mechanical impact, and vibration—critical for machinery exposed to dust, debris, and constant jarring. It operates seamlessly across a -55°C to +85°C temperature range, performing reliably in freezing outdoor conditions or sweltering factory floors. With 25,000+ electrical cycles and 50,000+ mechanical cycles, it endures frequent actuation without degradation.
The ergonomic metal toggle lever provides crisp tactile feedback, enabling precise operation even with gloved hands, while its compact design fits standard control panels for easy integration. Certified to CE and UL standards, the HT802 Series meets global safety regulations, ensuring compliance for international heavy machinery projects.
For engineers and operators seeking a durable, high-performance toggle switch for heavy equipment, the HT802 Series stands as a dependable choice, blending ruggedness, versatility, and safety in one purpose-driven component.
FAQ
Q1: When can I get the quotation ?
A: We are online all day, so you can get quotation within 24h.
Q2: When can I get the samples?
A: It depends on the express, generally 3-10 days.
Q3: Can you accept small order?
A: Yes, we will try our best to help you with your business.
Q4: What's the lead time of mass production?
A: Generally 2-4weeks. We will inform you the delivery time after receiving your payment.
| SPECIFICATION |
| CONTACT RESISTANCE: | 20m ohm(Max) |
| INSULATION RESISTANCE: | 100VDC-100M ohm(Min) |
| DIELECTRIC STRENGTH: | 1500VAC-1MINUTE |
| MECHANICAL LIFE CYCLE: | 100.000 CYCLES |
| OPERATING TEMPERATURE: | -40 to +85 DEGREES |
| FRONT SEAL: | IP68 |
| RATING |
| RESISTIVE LOAD: | 16A 125/250VAC,15A 28VDC |
| INDUCTIVE LOAD: | 15A 28VDC |
| MATERIAL |
| ACTUATOR: | COPPER ALLOY |
| HOUSING: | NYLON (UL94V-0) |
| BUSHING: | ZINC ALLOY |
| TERMINAL: | COPPER ALLOY |
| CONTACT: | COPPER ALLOY |
| O-RING: | SILICONE RUBBER |
| SHEEL: | STAINLESS STELL |
